Facility Locations

Unit-I

Located at 65, Industrial Estate, Bhilai, India Unit I is a light and medium machine building facility with a manufacturing capacity of 12000 MT per annum. Here we can handle a single piece job up-to 50 Tons.

In addition to regular machines such as Lathes, Plano Miller, Cylindrical Grinders, Surface Grinders, this unit is equipped witd several CNC Machines, Heat Treatment facility, EOT Cranes and Mobile Material Handling equipment.

simplex Four star
Plot Area 50200 Square Metres.
Covered Area 23166 Square Metres.
Number of Machine Tools 84 (54 Conventional + 30 CNC).
Handling Facilities 19 EOT Cranes (50/30/10/5/3-Ton), 3 Mobile Cranes (10-Ton).
Captive Power Generators [for emergency] 765 KVA.
Heat Treatment Facilities Electrical Heat Treatment Furnace, Water Quenching facilities, Oil quenching facilities and Induction Hardening Facilities.
Fabrication Facilities Plate Bending Machines, CNC Flame Cutting Machine, SAW, MIG, TIG, Rectifiers.
Testing Facilities Ultrasonic Testing Machine, Magnetic Particle Testing Machine, Ultrasonic Surface Finish Tester, Die-Penetrant Testing Facility.
Unit-II

Located at 11, Industrial Estate, Bhilai, India Unit II is a heavy machine building and technological fabrication division with capacity of 20000 MT per annum. Here we can handle a single piece job up-to 80 Ton in single piece.

The Unit is equipped with a series of Vertical Boring Machines. A job with dia 8 mtr and height 5.5 mts can be machined on Vertical Boring Machines most which are CNCs. Apart from above, this Unit also has Horizontal Boring Machines, Planno Millers etc of various sizes.

simplex richard boring machine
Plot Area 50200 Square Metres.
Covered Area 33310 Square Metres.
Number of Machine Tools 62.
Handling Facilities
EOT Crane10T-2
EOT Crane30T-5
EOT Crane50T-8
Mobile pick & carry crane 10T Cap -3Nos
Captive Power Generators [for emergency] 500 KVA-2Nos ( D.G. Set)
Fabrication Facilities
A. Plate bending machine -Capacity up to 60 mm thick x 4000 mm width
B. Plate bending machine() -Capacity up to 32 mm thick x 2500 mm width
C. CNC Flame cutting machine - Capacity up to 80 mm thick x 3000 mm width x 12500 mm long
D. Strip Flame cutting machine - Capacity up to 80 mm thick x 3000 mm width x 12500 mm long
E. SAW machine(moving on rails) - 04 nos.
F. SAW machine with movable welding head - 04 nos.
G. MIG welding rectifier - 20 nos
H. Beam flange straightning machine
I. Welding rectifier - 40 nos.
Shot blasting & Painting booth
A. Scerw type Air Compressure - 2Nos
B. Grit Blasting Equipment - 2Nos
C. Blasting Booth - 2Nos
D. Painting Shop - 1Nos
E. Painting Booth - 2Nos.
Testing Facilities
A. Ultrasonic Testing Machine-2Nos
B. Ultrasonic Thicknes Gauge-1Nos
C. Magnatic Particale Testing Machine(production Type)- 1Nos
Instrunment for Painting Shop
A. DFT (Dry Film Thickness) Meter
B. WET - Comb Gauge
C. Cross Hutch Cutter
D. Surface Comprator
E. Surface profile digital Gauges
F. Press-O- film
G. Hygrometer
Unit-III

Located in Tedesara, Rajnandgaon at a distance of 25 Kms from Bhilai, Unit III is a Heavy Machine building and technological fabrication division with capacity of 20000 MT per annum. Here we can handle a single piece job up-to 50 Ton in single piece.

Unit 3 is a heavy machining facility with more than 85 Machine tools. This Unit is equipped with a series of Horizontal Boring Machines apart from medium size Vertical Boring Machines, Planno Millers, Lathes, Automatic H beam line, 3 Axis CNC Drilling, Robotic welding, Plasma cutting, CNC Hydrulic press, Grid blasting and Enclosure etc.

simplex CNC Vertical Boring Machine
Plot Area 123001 Square Metres.
Covered Area 49192 Square Metres.
Types of Machine Tool Horizontal Boring Machines, Vertical Boring Machines, Lathe Machines, Shapers, Slotters, Drilling Machines, Planno Millers, etc.
Handling Facilities 19 EOT Cranes (50/30/10/6-Ton), 6 Mobile Cranes (10/8-Ton).
Captive Power Generators [for emergency] 1150 KVA.
Fabrication Facilities Plate Bending Machines, CNC Flame Cutting Machines, Welding Manipulators, SAW, MIG, TIG,Rectifiers, Grit Blasting Equipment, Hydraulic Presses (Vertical Cylinder, Vertical Double Cylinder, Horizontal Double Cylinder).
Heat Treatment Facilities Stress Relieving Furnace (4m x 6m x 8 m) 1.
Testing Facilities Ultrasonic Testing Machine, X-Ray Testing Equipment, Magnetic Particle Testing Machine, Ultrasonic Surface Finish Tester, Die-Penetrant Testing Facility, Digital Hardness Tester, RAM Testing Facility (1:4), Flow Meter, Pump Testing Bench, Hydraulic Testing Bench, Digital Height Gauge.
Unit-IV

Unit-IV is the youngest unit built to add further fabrication capacity. Built in four acres land it has one single covered shed of size 130 m x 18 m with EOT crane of 50 MT. It has all fabrication facilities like pug cutting machines, welding rectifiers, submerged arc welding machines, radial drills, hand grinders, grit blasting enclosure and painting compressor. It has a capacity of 100 MT per month.
